HIOKI 8807-51 MEMORY HiCORDER

Instantaneous Analysis and Long-term Recording of Harmonic Waves for Maintenance of Commercial Power Systems : - Measure harmonics up to 40 orders from the fundamental wave - Analysis display includes RMS value, content factor, phase angle, active power, and power phase angle for each order of harmonics (numeric and graphic display) - Analysis display of total RMS value, total deitortion, active/ reactive/ apparent power, and power factor (numeric display) - Bar graph and numeric data display - Power phase angle can be displayed as a vector Basic specifications : Measurement ranges : 10 mV to 100 V/division, 13 ranges (10 division f.s.), resolution: 1/160 of range, AC voltage for possible measurement/ display using the memory function : 450 V rms * 100 V/division excludes the RMS & memory recorder function Frequency characteristic : DC to 50 kHz ±3 dB Time axisat memory recorder function : 200 µs to 5 minutes/division, 19 settings (1 division =80 samples) Measurement functions : (1)Memory recorder, (2)Recorder, (3)RMS recorder & memory (50/60 Hz or DC only) (4)Harmonic wave analysis (Time series analysis mode), (5)Harmonic wave analysis (Instantaneous analysis mode) Number of input channels : Analog (2 channels standard) + logic (8 channels standard) *fixed input section Memory capacity : 256 k words/ch (using CH1) to 128 k words/ch (using CH1 & CH2) Data storage : Type II PC card slot (9727/ 9728/ 9729 PC card, 256MB to 1GB) Interfaces : RS-232C (the optional RS-232C CABLE 9612 is required for connection to PC) Interfaces (optional, sold separately) : Detachable printer: PRINTER UNIT 8992 can be connected Recording and display : 5.7-inch STN color LCD, 112 mm (4.4 in) × 18 m (59.06 ft), thermal paper roll Other functions : DMM function (voltage shown as numerals on the display), Scaling, Parameter calculations, Cursor readout, etc. Power supply : 100 to 240V AC (50/60 Hz) with use the AC ADAPTER 9418-10 (option) BATTERY PACK 9447 (Continuous use 3 hours) (option) LR6 (AA) × 6 (Continuous use 1 hours) (LR6 batteries cannot be used with PRINTER UNIT 8992) Dimensions, mass : 203 mm(7.99 in)W × 170 mm(6.69 in)H × 52 mm(2.05 in)D, 1.1 kg (38.8 oz) 280 mm(11.02 in)W × 170 mm(6.69 in)H × 52 mm(2.05 in)D, 1.5 kg (52.91 oz) (printer attached) Accessories : LR6/AA alkaline batteries (6), alkaline battery box (1), shoulder belt (1)
